Main Features Chipset INTEL B760 Form Factor m-ATX Supported CPU Support for LGA1700 slots The 12th/13th/4th Gen processors TDP: 125W(8 1 1) Memory Specifications Maximum Memory 96GB Supported Memory Support for 4800/5600/6400MHz OC memory frequency Connector & ports Audio Jack Realtek® ALC897 Codec 5.1-Channel High Definition Audio HDMI 1x HDMI port Supported Storage 3x M.2 slots (2242 / 2280 PCIE X4 / X2 channel SSD supported only) 4x SATA 3.0 ports Generel information Audio Feature Integrated REALTEK ALC 897 sound chip Channel Supported Support for dual-channel memory technology Display Port 1x DisplayPort 1.4 Expansion Slots 1x PCIE X16 4.0 slot 5.0 slot 1x PCIE X1 3.0 slot Support for AMD and NVIDIA and INTEL graphics cards Support for PCIE resizable bar technology LAN Integrated REALTEK 8125 chip (10 / 100 / 1000 / 2500Mbit) 1x onboard R]45 port Support network arousal Support PXE no disk, UEFI no disk guide Number of Memory Slots 2 RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Wireless Communication module Intel AX211 WIFI6E Wireless Card Warranty Information Warranty 3 Year Warranty MAXSUN B760M GAMING WIFI ACE m-ATX DDR5 Motherboard The MAXSUN B760M GAMING WIFI ACE m-ATX DDR5 Motherboard is a high-performance motherboard designed for gamers and enthusiasts seeking the latest in technology and connectivity. Built around the Intel B760 chipset, this motherboard supports LGA1700 slots and is compatible with 12th, 13th, and upcoming 4th Gen Intel® Core™ processors. With its m-ATX form factor, it offers a compact yet powerful foundation for building a gaming or high-performance PC. Memory Performance is a highlight of this motherboard, supporting up to 96GB of DDR5 memory across two slots. It also provides support for dual-channel memory technology, ensuring faster data access and improved system responsiveness. The motherboard allows for memory overclocking, reaching frequencies of 4800, 5600, and even up to 6400MHz, making it ideal for high-performance tasks and demanding gaming scenarios. For expansion needs, the MAXSUN B760M GAMING WIFI ACE is equipped with one PCIe 4.0 x16 slot and one PCIe 3.0 x1 slot, supporting AMD, NVIDIA, and Intel graphics cards. It also features PCIe resizable bar technology, optimizing GPU performance by dynamically allocating memory access for more efficient gaming. In terms of storage, this motherboard offers three M.2 slots supporting PCIe X4/X2 channel SSDs for lightning-fast data transfer and storage speeds, as well as four SATA 3.0 ports for additional storage devices. For network connectivity, it includes a Realtek® 8125 chip supporting speeds up to 2.5Gbps and an Intel® AX211 Wi-Fi 6E wireless card for fast, stable wireless connections and Bluetooth® support. Audio is powered by the Realtek® ALC897 codec, delivering 5.1-channel high-definition sound. This motherboard also offers RAID support for SATA storage devices, with RAID 0, 1, 5, and 10 configurations for data redundancy and performance optimization. Backed by a 3-year warranty, the MAXSUN B760M GAMING WIFI ACE delivers reliability, power, and performance. MAXSUN B760M GAMING WIFI ACE m-ATX DDR5 Motherboard Features CPU Compatibility: Supports 12th, 13th, and upcoming 4th Gen Intel® Core™ processors, Pentium® Gold, and Celeron® processors with LGA1700 sockets. Memory Support: Features dual-channel memory technology, with 2 DDR5 slots supporting up to 96GB of RAM. It offers memory overclocking with speeds of 4800MHz, 5600MHz, and 6400MHz, ensuring high performance for gaming and multitasking. Expansion Slots: Equipped with one PCIe 4.0 x16 slot for graphics cards, and one PCIe 3.0 x1 slot. It supports AMD, NVIDIA, and Intel GPUs and PCIe resizable bar technology for optimized GPU performance. Storage Options: Comes with three M.2 slots (PCIe X4/X2) for high-speed SSDs, and four SATA 3.0 ports for additional storage devices. Networking: Integrated Realtek 8125 chip with 2.5Gbps LAN support for fast, wired internet connectivity, and an Intel AX211 Wi-Fi 6E wireless card for advanced wireless communication and Bluetooth® support. Audio: Features Realtek® ALC897 codec, providing 5.1-channel high-definition audio for immersive sound quality during gaming and media playback. Connectivity: Includes 1 HDMI port, 1 DisplayPort 1.4, and support for multiple USB ports, ensuring flexible connectivity options for peripherals and displays. RAID Support: Supports RAID 0, 1, 5, and 10 for SATA storage, offering data redundancy and improved storage performance. Compact Form Factor: Built in the m-ATX form factor, making it ideal for smaller gaming builds without sacrificing performance. 3-Year Warranty: Provides peace of mind with a 3-year manufacturer warranty, ensuring durability and long-term support.
