Combo Graphics Card 1x VGA *Support VGA, maximum resolution of 2048×1536 50Hz, 2048×1280 60Hz, 1920×1200 60Hz 1x HDMI port *HDMI port supports up to 4K 30Hz *Graphics specifications may vary between CPU types. Processor CPU Socket AMD Socket AM4, support for: AMD Ryzen 5000 G-Series Processors/ AMD Ryzen 5000 Series Processors/ AMD Ryzen 4000 G-Series Processors/ AMD Ryzen 3000 Series Processors Mainboard Chipset AMD B450 Chipset Memory Memory 2x DDR4, Maximum Memory Capacity 64GB Memory Support DDR4 3200(OC)/ 2933(OC)/ 2666(OC)/ 2400(OC) MHz Supports AMD A-XMP OC Supports Dual-Controller Dual-Channel mode Storage Storage M.2 slot (Key M), type 2242/2280 (supports PCIe 4.0 x4 mode) 4x SATA 6Gb/s ports Audio & Microphone Audio Realtek ALC897 Codec 5.1-Channel High Definition Audio Networking & Connectivity LAN Realtek RTL8111H 1G LAN Technical Info LED Indicators Without Debug LED Supported OS Support for Windows 11 64-bit, Windows 10 64-bit Ports Internal I/O Ports 1x 24-pin Power Connector(ATX_PWR) 1x 4-pin Power Connector(CPU_PWR) 1x CPU Fan 1x System Fan 1x PS/2 interface 1x M.2 slots (Key-M) 4x SATA 6Gb/s ports 1x 4-Pin SPEAKER 1x Front Audio 1x COM_A Port 1x 9-Pin DEBUG_CON 1x CLR CMOS USB *Front USB (Total 4 ports) 2x USB 3.2 Gen1 Type A 2x USB 2.0 *Rear USB (Total 4 ports) 2x USB 3.2 Gen1 Type A 2x USB 2.0 Physical Specification Expansion Slots 1x PCIe 3.0 x16 slot 1x PCIe 3.0 x1 slot Form Factor M-ATX Dimension 220mm x 175mm Others Other Features RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Warranty Information Warranty 3 Years
